Jupyter: Notebooks and Data Analysis

Run JupyterLab with Pigsty’s standalone Docker Compose template and access PostgreSQL safely.

JupyterLab is an interactive notebook, terminal, and data-analysis environment. Pigsty v4.5.0 has two distinct deployment paths:

The VIBE module, managed by Ansible and systemd, for the complete v4.5.0 development sandbox.
The lightweight standalone app/jupyter Docker Compose template documented here.

app/jupyter is not a default apps inventory entry. Prepare its data directory separately. app.yml -e app=jupyter does not handle directory ownership.

Quick Start

cd ~/pigsty/app/jupyter
vi .env                    # change JUPYTER_TOKEN and optionally pin JUPYTER_IMAGE
chmod 600 .env
make dir                   # create /data/jupyter, owned by 1000:100
make up                    # docker compose up -d

Generate a strong token with openssl rand -hex 32. The default port is 8888; open http://<host_ip>:8888.

lab.pigsty works only when that name is configured in infra_portal, Nginx, and DNS. The template default JUPYTER_TOKEN=pigsty is for local demonstrations only and must be replaced in production.

Current Template

The v4.5.0 .env defaults are:

JUPYTER_IMAGE=quay.io/jupyter/minimal-notebook:latest
JUPYTER_PORT=8888
JUPYTER_TOKEN=pigsty

Compose mounts host /data/jupyter at /home/jovyan/work and passes the token into the container. The upstream latest tag changes. Production deployments should use a tested image tag or digest.

For SciPy, R, Julia, TensorFlow, PyTorch, or Spark, select another Jupyter Docker Stacks image from .env. Pin its version and validate architecture support.

Access PostgreSQL

Install the modern Psycopg driver and optional analysis libraries from a Jupyter terminal:

pip install "psycopg[binary]" pandas sqlalchemy

Do not store real passwords in notebooks. This example obtains the connection string through hidden input and reads system information only:

from getpass import getpass
import psycopg

pgurl = getpass("PostgreSQL URL: ")
with psycopg.connect(pgurl) as conn:
    with conn.cursor() as cur:
        cur.execute("SELECT current_database(), current_user, version()")
        print(cur.fetchone())

Use Pandas and SQLAlchemy with a system statistics view:

import pandas as pd
from sqlalchemy import create_engine

engine = create_engine(pgurl)
df = pd.read_sql(
    "SELECT datname, numbackends, xact_commit, xact_rollback "
    "FROM pg_stat_database ORDER BY datname",
    engine,
)
df

These examples access system views only. Obtain authorization from the data owner before reading application tables, and limit columns, predicates, and result size.

Persistence and Dependencies

Only /home/jovyan/work is mapped to /data/jupyter. The following are not persistent across container recreation by default:

Python or Conda packages installed temporarily inside the container
notebooks, configuration, and caches outside work
the container’s own user state

For production, install dependencies with a pinned image, custom Dockerfile, or reproducible dependency file. Back up /data/jupyter separately. A persistent mount is not a backup.

Management Commands

From ~/pigsty/app/jupyter:

make up      # start JupyterLab
make dir     # create the data directory with 1000:100 ownership
make view    # show access endpoints
make log     # follow logs
make info    # inspect the container
make stop    # stop the container
make pull    # pull the image selected in .env

make clean removes the container and retains /data/jupyter. make purge recursively deletes /data/jupyter, and this deletion is unrecoverable. Confirm the exact directory and a recent backup before running it.

Security Checklist

Use a strong random token, protect .env, and do not disable authentication.
The default port mapping listens on the host network. Restrict sources with a firewall and prefer Nginx with valid HTTPS.
A notebook can execute arbitrary code and access mounted files and databases. Grant only least-privilege database accounts and host directories.
Pin and scan the image, and validate dependency upgrades reproducibly.
Back up /data/jupyter regularly and test restoration to a temporary directory.
